Reduced price! HES 1600 Faceplates & Specialty Option Kits View larger

HES

HES 1600 Faceplates & Specialty Option Kits

Item normally ships out within 1-2 Weeks (excluding transit time). If out of stock it can take up to 3-4 weeks (excluding transit time). Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.

$124.20

40% Off

$207.00

Details: HES 1600 Faceplates & Specialty Option Kits

HES 1500 & 1600 Series Electric Strike Faceplate Options. After releasing the latchbolt, the keeper returns to the locked position

1LB Faceplate Option

The Latchbolt Solution: Includes the hardware to accommodate every cylindrical and mortise lock up to a 3/4" latchbolt. For metal frame applications.

1J (4-7/8" × 1-1/4")
For use with cylindrical locksets up to 3/4" throw and all locksets with center-lined bolts. ANSI/BHMA Numbers: #E09321, #E09322, #E09323
1K (4-7/8" × 1-1/4")
For use with Mortise locksets with a deadlatch positioned above the latchbolt. Compatible Locksets: Baldwin, Marks, PDQ, Others. ANSI/BHMA Numbers: #E09321, #E09322, #E09323
1KD (4-7/8" × 1-1/4")
For use with Mortise locksets with a deadlatch positioned above the latchbolt. Compatible Locksets: Jackson, Sargent (7700 & 8100), Schlage, Yale (8700). ANSI/BHMA Numbers: #E09321, #E09322, #E09323
1KM (4-7/8" × 1-1/4")
For use with Mortise locksets with a deadlatch positioned below the latchbolt. Compatible Locksets: Accurate, Arrow, Best*, Corbin/Russwin, Falcon (1992 M Series), Sargent (7800, 8200 & 9200 series), Yale (8800) *For Best 45H &47H deadlatch below, and Best 34H - 37Hdeadlatch above. ANSI/BHMA Numbers: #E09321, #E09322, #E09323<dd>

1LB-2 Faceplate Option

The Latchbolt Solution: Includes the hardware to accommodate every cylindrical and mortise lock up to a 3/4" latchbolt. For wood frame applications.

1J-2 (9" × 1-3/8)
For use with cylindrical locksets with up to a 3/4" throw, in wood frame applications. ANSI/BHMANumbers: #E09321, #E09322, #E09323
1KM-2 (9" × 1-3/8")
For use with Mortise locksets with a deadlatch positioned below the latchbolt, in wood frame applications. Compatible Locksets: Accurate, Arrow, Best*, Corbin/Russwin, Falcon (1992 M Series), Sargent (7800, 8200 & 9200 series), Yale (8800). *For Best 45H &47H deadlatch below, and Best 34H - 37Hdeadlatch above. ANSI/BHMA Numbers: #E09321, #E09322, #E09323

Specifications

  • UL 10C fire-rated, 3 hour single door (fail secure only)
  • UL 10C fire-rated, 1-1/2 hour double door
  • CAN4-S104(ULC-S104) fire door conformant
  • ANSI/SDI 250.13 Windstorm resistant
  • ANSI-ASTM E330
  • Florida Building Code approved TAS 201, 202, 203
  • UL 1034 burglary-resistant listed and suitable for outdoor use
  • UL 294 (6th Edition) listed
  • ANSI/BHMA A156.31, Grade 1
  • NFPA-252 fire door conformant
  • ASTM-E152 fire door conformant
  • California Fire Marshal listed
  • PoE friendly
  • RoHS compliant
  • Patents pending

Finishes

  • 630 - Satin stainless steel
  • 605 - Bright brass
  • 606 - Satin brass
  • 612 - Satin bronze
  • 613E - Dark oxidized satin bronze
  • 629 - Bright stainless steel
  • BLK - Black suede, *Complete Pacs are only available in the 630 finish

Specifications & Options

Strike Type
Mortise
Security
Fail Secure
Duty
Heavy Duty (Grade 1)
Door Frame
Wood, Hollow Metal
Monitoring
Latchbolt
Bolt Throw / Projection
3/4"
Rating
Fire-Rated

HES Electric Strike Comparison Chart

With DeadboltWithout Deadbolt
Certifications & ListingsHES 1600HES 1006CompetitorHES 1500HES 4500Competitor
UL10C, 3 hour single door fire-ratedYYYYYY
UL10C, 1-1/2 hour doubled door fire-ratedYYNYNN
CAN4-S104(ULC-S104) fire door conformantYYYYYY
UL 1034 burglary-resistant listedYYYYYY
UL 1034 burglary-resistant listed for outdoor useY*YNY*NN
UL 294(6th Edition) listedYYNYYN
Environmental Product DeclarationIntendedYNIntendedIntendedN
ANSI/BHMA A156.31, Grade 1YYYYYY
NFPA-252 fire door conformantYYYYYY
ASTM-E152 fire door conformantYYYYYY
Windstorm Resistant ANSI-ASTM E330 Florida Building Code approved TAS 201, 202, 203YYNYNN
California Fire Marshal listedIntendedNNIntendedYN
RoHS compliantYY?YY?
Patented designAppliedYAppliedAppliedYApplied
Standard FeaturesHES 1600HES 1006CompetitorHES 1500HES 4500Competitor
Accommodates cylindrical and mortise latchboltsYYYYYY
Accommodates all brands of mortise locksYYYYNY
Accommodates 1" deadboltsYYYNNN
Release and recapture 1" deadboltNYNNNN
Installs in fire listed 2" frame with 1/2" drywallNNNYYY
Strike body depth1-5/8"1-11/16"1-5/8"1-3/8"1-3/8"1-3/8"
Strike cavity height3-1/4"3-1/4"3-1/4"3-1/4"2-11/16"3-1/4"
Tamper resistant, stainless steel constructionYYYYYY
Static strength (lbs)150030701500150030003,250 Factory Test
Dynamic strength (ft-lbs)70350707070-
Endurance (cycles)1M*1M2M Factory Test1M*1M1M
All wearing parts field replaceable - earth friendlyYNNYNN
Full finished face plate, keeper, case and trimYNNYNY
Field selectable fail safe/fail secureY^NYY^YN
non-handedYYYYYY
Horizontal adjustmentIntigratedShimsShimsIntigratedShimsShims
Plug-in connectorYYYYYY
Trim enhancer includedYYYYYY
Lip extension (sizes)1/2"1+"N1/2"N1/4"
Latchbolt MonitorField Install°YField InstallField Install°YY
Latchbolt and Door Position MonitorFactory InstallNNFactory Install°NN
Strike Locked MonitorYNNYYN
Metal template kit for easy installationYYNYYN
Frame typeAllAllAllAllAllAll
Available finishes771776
Standard ElectricalHES 1600HES 1006CompetitorHES 1500HES 4500Competitor
Dual voltage 12 or 24YYYYYY
AC or DCYNYYYY
Current at 12 volts0.24 A0.45 A0.38 A0.24 A0.24 A0.24 A
Current at 24 volts0.12 A0.25 A0.19 A0.12 A0.12 A0.11 A
Continuous dutyYYYYYY
PoE friendly (under 0/25 amps) (Standard solenoid)YNYYYY
EcoStrike ElectricalHES 1600HES 1006CompetitorHES 1500HES 4500Competitor
Auto sensing 12 -24 VDCYY
Operating voltage 10-30 VDC, continuous dutyYY
Max voltage 32 VDCYY
Minimum on-time 1.25 secondsYY
Current at 12 volts after 1.25 seconds0.009A0.009A
Current at 24 volts after 1.25 seconds0.005A0.005A
PoE friendly (under 0.25 amps)Y**Y**
* EcoStrike is not Outdoor rated. The EcoStrike cycle rating is 500,000; ** Temporary in-rush 0.460A at 12 VDC/0.220A at 24VDC; ° Order non-standard option factory installed. ; ^ EcoStrike is not field selectable;

Lock Cross Reference

ANSI Lock DescriptionManufactuterElectric Strikes

Mortise, Locksets,

Mortise lockset, without a deadbolt		Arrow, Baldwin, Best, Marks, Omnia, PDQ 1600CS, 1006CS, 1600CLB, 1006CLB, RF1006CLB, IC1006CLB, 1600-1LB, 1006KM, RF1006-KM, IC1006-KM, 1500C, 4500C, RF4500, IC4500, 742-75
Corbin Russwin, ML2000 and, Arrow1600CS, 1006CS, 1600CLB, RF1006CLB, IC1006CLB 1600-1LB, 1006-KM, , RF1006-KM, IC1006-KM, 1500C, 4500C, RF4500, IC4500, 8500-852K, RF8500-852K, IC8500-852K, 742-75
Sargent 7700, 8100, Schlage L*1600CS, 1006CS, 1600CLB, 1006CLB, RF1006CLB, IC1006CLB, 1600-1LB, 1006-KD, RF1006-KD, IC1006-KD, 1500C, 4500C, RF4500, IC4500, *8500-852L, RF8500-852L, IC8500-, 852L(Schlage L), 742-75
Sargent 7900, 8200, 92001600CS, 1006CS, 1600CLB, 1006CLB, RF1006CLB, IC1006CLB, 1600-1LB, 1006-KM, RF1006-KM, IC1006-KM, 1500C, 4500C, 8500-851M, RF8500-851M, IC8500-851M, 742-75
Accurate, Falcon, Kaba, Ilco/Unican, Yale 8700, (manufactured, after 2005), Yale 88001600CS, 1006CS, 1600CLB, 1006CLB, RF1006CLB, IC1006CLB, 1600-1LB, 1006-KD, RF1006-KD, IC1006-KD 1500C, 4500C, RF4500, IC4500, 8500-852M, RF8500-852M, IC8500-852M

Mortise, Locksets

Mortise lockset, with a , 1" deadbolt		Accurate, Almet, Arrow, Baldwin, Best, Marks, Corbin, Russwin, Falcon, Omnia, PDQ Schlage1600CS, 1006CS, 1600CDB, 1006CDB, RF1006DBL, IC1006CDB, 1600-1DB, 1006-AM*, 1006-HM*, 1006-, NM, 1006T*
Sargent, Yale1600CS, 1006CS, 1600CDB, 1006CDB, RF1006DBL, IC1006CDB, 1600-1DB, 1006-AD*, 1006-HD, 1006-ND

Cylindrical , lockset

Latchbolt for, aluminum stile, doors		All, manufacturers5000, RF5000, IC5000, 1600-1LB, 1006-J, 7000C, RF7000, 1500C, IC7000, 5200, RF5200, IC5200

Cylindrical , lockset

Cylindrical lockset, up to 5/8" throw		All manufacturers1600CS, 1006CS, 5000, RF5000, IC5000, 7000C, RF7000, IC7000, 8000, RF8000, IC8000, 8300, RF8300, IC8300, V3, 712, 310-2

Cylindrical , lockset

Cylindrical lockset, up to 3/4" throw		All Manufacturers1600CS, 1006CS, 1600CLB, 1006CLB, RF1006CLB, IC1006CLB, 1600-1LB, 1006-J, RF1006-J, IC1006-J, 5200, RF5200, IC5200, 1500C, 4500C, RF4500, IC4500, 4500, RF7500, IC7500, 712-75, 310-75

Rim mounted

Rim mounted exit, device up to 1/2", throw		All Manufacturers7000-789, RF7000-789, IC7000-789, 9400, RF9400, IC9400

Rim mounted

Rim mounted exit, device up to 3/4", throw		All Manufacturers7000-783, RF7000-783, IC7000-783, 7000-786, RF7000-786, IC7000-786, 9500, RF9500, IC9500, 9600, RF9600, IC9600, 310-4

Rim mounted

Rim mounted exit, deadbolt		Corbin Russwin, (Secure Bolt), Yale (Square, Bolt),9700, 310-4S

HES and Folger Adam electric strikes are designed to be installed in accordance with the ANSI/BHMA A156.31 4-7/8" jam preparation.

When accommodating a cylindrical lock, the electric strike is to be installed centerline to centerline.

When accommodating a mortise lock, the centerline of the electric strike is to be installed 3/8" above the centerline of the mortise lock, except asnoted for individual strikes. Folger Adam 712 series and 310 series will need special alignment with used with a mortise lock.

HES electric strikes are all non-handed and designed for installation in hollow metal, concrete filled metal, aluminum and wood jambs.

Folger Adam electric strikes are all non-handed and designed for installation in hollow metal, aluminum and wood jambs.

Electric strikes can be installed in a wide range of swinging door applications.

Consider these factors to help determine the right electric strike for your project.

Assess the type of frame and health of the opening

  • Material: hollow metal, aluminum or wood?
    Adams Rite offers electric strikes for aluminum, hollow metal or wood doors. Please see the Adams Rite catalog to order the compatible model for your door application.
  • Type: hollow or concrete-filled? Concrete-filled may require additional tools. Consider using no-cut electric strikes.
  • Health of door and frame: can frame or door irregularities be fixed prior to electric strike installation?

Determine if door assembly has special requirements

  • Fire-rated Assembly (NFPA 80 Fire Doors)
  • Windstorm Resistant (tested to sustain winds up to 150 mph)
  • Outdoor Rated (UL 1034)
  • Preload Capable

Identify and test existing door hardware

  • Existing locking hardware determines the compatible electric strike and overall function of the opening

Common Accessory

2005M3 Smart Pac® III

Reduces initial voltage in timed or fail safe operations by 25% to extend the life of the electric strike.

Addition of Smart Pac to any HES electric strike extends the 5-year no-fault warranty to a 10-year no-fault warranty.

Cylindrical PictureCylindrical with
1/2", 5/8", 3/4" Latchbolt
HES 1600, 1006, 1500
Fire Rated Picture

Fire Rated

Windstorm Resistant Picture

Windstorm Resistant

Outdoor Rated Picture

Outdoor Rated

HES 5000
Outdoor Rated Picture

Outdoor Rated

HES 5200
HES 7501
Fire Rated Picture

Fire Rated

Preload Picture

Preload

up to 15 lbs
HES 8000
Outdoor Rated Picture

Outdoor Rated

no-cut
HES 8300
Fire Rated Picture

Fire Rated

Outdoor Rated Picture

Outdoor Rated

Adams Rite 7100 Series
Adams Rite Ultraline® 7400 Series
Preload Picture

Preload

up to 25 lbs
Mortise Lockset without a DeadboltMortise Lockset without a Deadbolt
up to 3/4" Throw Latchbolt
HES 1600, 1006, 1500
Fire Rated Picture

Fire Rated

Windstorm Resistant Picture

Windstorm Resistant

Outdoor Rated Picture

Outdoor Rated

HES 8500
Fire Rated Picture

Fire Rated

Outdoor Rated Picture

Outdoor Rated

no-cut
Adams Rite 7160
Mortise Lockset with a DeadboltMortise Lockset with a 1" Deadbolt
HES 1600, 1006
Fire Rated Picture

Fire Rated

Windstorm Resistant Picture

Windstorm Resistant

Outdoor Rated Picture

Outdoor Rated

Mortise Lockset without a DeadboltRim Exit Devices up to 1/2" Throw Latchbolt
HES 9400
Outdoor Rated Picture

Outdoor Rated

no-cut
surface mounted		Adams Rite Ultraline® 74R2
Preload Picture

Preload

up to 25 lbs
Mortise Lockset without a DeadboltRim Exit Devices up to 3/4" Pullman Latchbolt
HES 7000
Preload Picture

Preload

up to 15 lbs
HES 9500
Fire Rated Picture

Fire Rated

Outdoor Rated Picture

Outdoor Rated

no-cut
surface mounted
HES 9600
Windstorm Resistant Picture

Windstorm Resistant

Outdoor Rated Picture

Outdoor Rated

no-cut
surface mounted
Adams Rite Ultraline® 74R1
Preload Picture

Preload

up to 25 lbs
Mortise Lockset without a DeadboltRim Exit Devices with Corbin Russwin
SecureBolt® or Yale SquareBolt®
HES 9700
Fire Rated Picture

Fire Rated

Windstorm Resistant Picture

Windstorm Resistant

Outdoor Rated Picture

Outdoor Rated

no-cut
surface mounted

Available Model Numbers and Combinations

Model/SKUAttributes
1LBBLK
1LB-2--630 1LB-2: 1J-2 & 1KM-2 Faceplates, Satin Stainless Steel
1LB-2-BLK 1LB-2: 1J-2 & 1KM-2 Faceplates,
1LB-2--613E 1LB-2: 1J-2 & 1KM-2 Faceplates,
1LB-2--605 1LB-2: 1J-2 & 1KM-2 Faceplates, Bright Brass
1LB-2--606 1LB-2: 1J-2 & 1KM-2 Faceplates, Satin Brass
1LB-2--612 1LB-2: 1J-2 & 1KM-2 Faceplates, Satin Bronze
1LB-2--629 1LB-2: 1J-2 & 1KM-2 Faceplates, Bright Stainless Steel
1LB-630 Satin Stainless Steel
1LB-613E
1LB-605 Bright Brass
1LB-606 Satin Brass
1LB-612 Satin Bronze
1LB-629 Bright Stainless Steel
