Schlage L Series Grade 1 Mortise Lock W/ M Collection Lever & Escutcheon Trim, Double Cylinder Non-Deadbolt

Item is normally in stock and ships out within 2-3 Business days (excluding transit time). If out of stock it can take up to 2-4 weeks (excluding transit time).Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.

Master Key:-

$1,169.87

30% Off

$1,671.24

?
?

Details: Schlage L Series Grade 1 Mortise Lock W/ M Collection Lever & Escutcheon Trim, Double Cylinder Non-Deadbolt

Designed for security, beauty, and flexibility, L Series features the most comprehensive list of functional, design, and trim options Schlage has to offer. Able to withstand the rigors of daily use without fail, these locks will stand the test of time and can serve the needs of all opening types.You can use L Series as part of a common aesthetic. They are made to suite with other Allegion products to present a quality, complete door hardware solution and provide a consistent user experience throughout your building or campus. L Series does all this while lowering the total cost of ownership through maintenance ease, key system flexibility and beautiful finishes that are made to last.

Schlage is committed to helping ensure safer classrooms and better privacy solutions with a family of lock status indicator trims. The large windows and 180-degree visibility of L Series indication trim lets you Know It's Locked even from across the room ensuring classroom, security, and privacy needs are met.

Features

  • Tested and certified to ANSI/BHMA Grade 1 operational and security standards
  • UL listed for 3-hour fire door; spring-loaded fusible link inside lock case provides fail secure mode in case of fire
  • Door thickness: 1-3/4" (44 mm) standard
  • Deadbolt features include anti-saw pin in bolt to prevent cut-through
  • Security blocking hub prevents lock access by removing levers
  • Vandlgard option allows the outside lever to rotate freely down to prevent damage from excessive force while in a locked state
  • Lock monitoring options include request to exit (RX), latchbolt (LX), door position (DPS), and deadbolt (DM) (availability varies by function)
  • Patented Everest 29 S123 keyway is provided standard which prohibits unauthorized key duplication
  • Lever styles constructed of solid brass or solid stainless steel offer a strong-yet-comfortable feel
  • 12 available finishes (depending on lever style) with options for antimicrobial coating
  • Locking lever bushing eliminates exposed screws on inside levers
  • 180-degree visibility indicator trim option for locked/unlocked status available for most functions. Available in both A style sectional and N style escutcheon designs
  • Lock status indication trim option uses red and white backgrounds to ensure quick readability for color blind individuals
  • Two piece anti-friction tongue in latch bolt reduces wear
  • Breakaway spindle keeps door secured in the event of vandalism
  • Field reversible latch bolt allows handing change without opening case
  • Every Schlage lock undergoes intensive testing to determine its ANSI grade level including: cycle, resistance, door impact, warped door and bolt strength tests
  • ANSI/BHMA A156.13-2017 Series 1000, Grade 1 operational and security
  • Complies with ICC A117.1 Accessible and Usable Buildings and Facilities
  • UL 10C and CAN/ULC-S104 listed 3-hour fire door (except L9076 and L9077)
  • All levers with a return to door of 1/2" (64 mm) or less comply (formerly Title 19, California State Fire Marshal Standard)
  • Miami-Dade NOA and Florida Building Commission listings
  • Texas Department of Insurance (TDI) for impact and non-impact applications
  • Meets BAA (Buy American Act)

Specifications

Case
Cold Rolled Steel (CRS) with corrosion resistant zinc dichromate plating
Case size
4-7/16" × 6-1/16" × 1" (113 mm × 154 mm × 25 mm)
Spacing
knob or lever to cylinder 3-7/8" (98 mm); knob or lever to thumbturn hub 2-11/16" (68 mm)
Door thickness
1-3/4" (44 mm) standard
L escutcheon
7-15/16" × 1-3/4" × 7/16" (202 mm × 44 mm × 11 mm); cold-forged brass and Stainless Steel
N escutcheons
7-7/8" × 2-1/2" × 7/16" (200 mm × 64 mm × 11 mm); heavy wrought reinforced brass, and Stainless Steel
Backset
2-3/4" (70 mm) only
Armor
Standard - 1-1/4" × 8" × 7/32" (32 mm × 203 mm × 6 mm)
Deadbolt
1" (25 mm) throw stainless steel
Latch
3/4" (19 mm) throw stainless steel with anti-friction tongue
Strike
ANSI curved lip strike 1-1/4" × 4-7/8" (32 mm × 124 mm) standard; dust box included
Strike lip length
1-3/16" (30 mm)

Applications

  • Commercial Real Estate
  • Healthcare
  • School & Educational Facilities
  • Retail

Downloads

Videos

Available Model Numbers and Combinations

Model/SKUAttributes
L9066 XL11-897-P-M84-N-619 KA Standard, Conventional 6-Pin, Keyed 5, Satin Nickel, Keyed Alike
L9082-C6-M63-L-605 LH KA Standard, Institution lock, Concealed Mortise 6-Pin, Bright Brass, Left Handed, Keyed Alike
L9066 XL11-897-W-M85-L-626 KA Standard, Satin Chrome, Keyed Alike
LV9071-P-M56-N-643e KA Vandlgard, Conventional 6-Pin, Keyed 5, Aged Bronze, Keyed Alike
LV9060-P6-M56-N-622 KA Vandlgard, Apartment entrance lock, Conventional 6-Pin, Matte Black, Keyed Alike
LV9077-L-M81-N-609 KD Vandlgard, Antique Brass, Keyed Different
LV9095EL-C6-ME2-N-629 LH KD Vandlgard, Concealed Mortise 6-Pin, Bright Stainless Steel, Left Handed, Keyed Different
L9066 XL11-897-C6-M61-L-630 LH MK Standard, Concealed Mortise 6-Pin, Satin Stainless Steel, Left Handed, Master Keyed
L9071-R-M63-N-625 LH KA Standard, Full Size Interchangeable Core, Bright Chrome, Left Handed, Keyed Alike
LV9060-P6-M56-N-629 KA Vandlgard, Apartment entrance lock, Conventional 6-Pin, Bright Stainless Steel, Keyed Alike
L9095EL-J-M63-L-629 RH KA Standard, Bright Stainless Steel, Right Handed, Keyed Alike
L9095EU-R-M63-N-629 LH MK Standard, Full Size Interchangeable Core, Bright Stainless Steel, Left Handed, Master Keyed
LV9095EU-C-M63-L-606 LH MK Vandlgard, Concealed Mortise 6-Pin, Keyed 5, Satin Brass, Left Handed, Master Keyed
L9082-C6-M63-L-629 RH KA Standard, Institution lock, Concealed Mortise 6-Pin, Bright Stainless Steel, Right Handed, Keyed Alike
LV9095EL-P6-ME1-L-619 RH KD Vandlgard, Conventional 6-Pin, Satin Nickel, Right Handed, Keyed Different
