  6. Rixson 195 3/4" Offset Jamb Mounted Pivot Set, Includes 180 Top Pivot
Reduced price! Rixson F195 Fire Rated ¾ Offset (Includes F180 Top Pivot) View larger

Rixson

Rixson 195 3/4" Offset Jamb Mounted Pivot Set, Includes 180 Top Pivot

Item normally ships out within 7-10 Weeks (excluding transit time). Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.

$653.59

40% Off

$1,089.32

?

Details: Rixson 195 3/4" Offset Jamb Mounted Pivot Set, Includes 180 Top Pivot

The 195 is an offset-hung, jamb-mounted pivot set designed for interior or exterior doors weighing up to 450lbs.

Features

  • Exterior or interior doors
  • Weight up to 450lbs. (door size & weight guidelines are determined using the appropriate number of intermediate pivots)
  • Door width up to 4'0" (1219mm)
  • Handed
  • 180 top pivot included; 119 or M19 intermediate pivots are recommended (sold separately)
  • Available for fire door assemblies up to three hours. Specify F195. F180 top pivot included; FM19 intermediate pivots are recommended (sold separately)
  • 3/4" (19mm) offset (measured from centerline of pivot to face of door)
  • Door edges must be beveled 1/8" in 2"
  • Bottom pivot mortised into side jamb
  • Pivot set can be vertically adjusted up to 3/16" (5mm) after installation without the use of shims
  • Doors will swing 180°, trim permitting
  • Non-ferrous base material
  • Doors 60" (1524mm) to 90" (2286mm) in height should use one intermediate pivot - each additional 30" (762mm) of door height warrants another intermediate pivot
  • Furnished with wood and machine screws
  • Available with extended spindles in 1/2" (13mm) increments up to 2" (51mm) longer than standard
  • Weight of door is borne by floor portion

Specifications

Hang Type
Offset hung
Maximum Door Weight
450 lbs
Certifications
ANSI/BHMA A156.4, Grade 2

Applications

  • Public Buildings & Facilities
  • Commercial & Industrial Buildings
  • Government & Military Facilities
  • Retail & Strip Malls
  • Multifamily & Mixed-Use

Downloads

Available Model Numbers and Combinations

Model/SKUAttributes
F195625LHEXT SPDL Left Hand,
195613LHTORX Left Hand,
195619RHTORX Right Hand,
195626RHTORX Right Hand,
F195626RHEXT SPDL Right Hand,
F195611RHEXT SPDL Right Hand,
195606LHTORX Left Hand,
195612LHTORX Left Hand,
F195611RHTORX Right Hand,
F195613ELH Left Hand,
195605LH Left Hand,
F195619LHEXT SPDL Left Hand,
F195613RHTORX Right Hand,
195612RH Right Hand,
195625LH Left Hand,

View All Model Numbers and Options
